What is the working principle of Labyrinth drip irrigation tape equipment？

The labyrinth drip irrigation tape is a highly efficient water-saving irrigation equipment. The working principle of the labyrinth drip irrigation tape equipment is mainly based on its unique labyrinth flow channel design and dripper structure to achieve local, micro and uniform irrigation.

Labyrinth flow channel structure

The labyrinth drip irrigation tape equipment is equipped with a special labyrinth flow channel. This flow channel is composed of a series of complex, maze-like small channels. The shape and size of these channels are carefully designed. If the water source water pressure causes the wall of the flow channel to produce resistance to the water flow due to some factors, the water flow cannot pass quickly, but continues to meander in the flow channel. This design can effectively reduce the speed of the water flow, evenly distribute the water flow, and prevent the dripper from clogging to a certain extent. Because even if the water flow carries tiny impurity particles, these particles are difficult to accumulate in the labyrinth flow channel and cause blockage.

Dripping process

1. When the water flows into the labyrinth drip irrigation belt, it will pass through the carefully designed labyrinth flow channel. The design of the labyrinth flow channel hinders the water flow when passing through, thereby slowing down the water flow speed and increasing the complexity of the water flow path.

2. Water droplets will form at the outlet due to factors such as surface tension. When the water flow slowly reaches the dripper outlet, at the edge of the outlet, the water gathers under the action of surface tension and gradually forms relatively uniform water droplets.

3. The dripper of the labyrinth drip irrigation tape is precisely designed to control the size and dripping speed of the water droplets.

4. The formed water droplets will drip into the soil near the roots of the crops under the action of gravity. This precise dripping method can directly supply water to the crop roots, avoiding a large amount of water evaporation and loss. Thereby effectively improving the utilization efficiency of irrigation water.

Advantages

Water saving and high efficiency: Labyrinth drip irrigation tape equipment can significantly improve water utilization and reduce water evaporation and waste.

Increased production and income: Since the roots of the crops are supplied with sufficient water, the yield of the crops is significantly increased. At the same time, the labyrinth drip irrigation tape can also be combined with fertilization technology to further improve fertilizer efficiency and crop yield.

Strong adaptability: Labyrinth drip irrigation tape equipment is suitable for a variety of crops and irrigation environments, such as fruit trees, vegetables, cash crops and greenhouse irrigation. In arid and water-scarce areas, labyrinth drip irrigation tapes have become an important water-saving irrigation method.

To sum up, the labyrinth drip irrigation tape equipment achieves local, micro-amount and uniform irrigation effects through its unique labyrinth channel design and dripper structure. This irrigation method not only improves water utilization and crop yields, but also reduces water evaporation and waste, providing strong support for the sustainable development of modern agriculture.
